The mPower Analog tool provides virtually unlimited power integrity scalability to transistor-level designs to enable fast, accurate, simulation-based, high-capacity dynamic EM/IR analysis on analog designs of any size—from the smallest bandgap reference to large analog systems and sensors.
HIGH CAPACITY DYNAMIC EM / IR ANALYSIS
The mPower solution brings scalability to transistor-level designs that were previously only available in the digital domain to enable simulation-based, high-capacity dynamic EM/IR analysis on large analog circuits that no other tool can handle.
FLEXIBILITY
The software provides flexibility on simulation and extraction with its ability to use any extractor to drive post-layout SPICE simulation, and any SPICE simulator that can write a fast signal database.
USER FRIENDLY
Ease of use
mPower Analog software fits into existing analog design and verification flows, uses industry-standard formats and employs simple and understandable TCL language to streamline implementation.
Additional ease-of-use benefits when used in conjunction with Siemens Calibre parasitic extraction tools and the Analog FastSPICE (AFS) platform.
